Switch Standard 48 (Gen1)
Dieser Artikel wurde eingestellt
Wir empfehlen die Verwendung des unten aufgeführten Produkts
Dieser Artikel wurde eingestellt
Wir empfehlen die Verwendung des unten aufgeführten Produkts
Verfügbare Alternativen
Detallierte Beschreibung
Der Switch 48 (US-48) ist ein völlig verwalteter, lüfterloser Switch mit 48 GbE RJ45-Anschlüssen, 2x 1G SFP-Anschlüssen und 2x 10G SFP-Anschlüssen. Der vielseitige US-48 ermöglicht Gigabit-Verbindungen zu Ethernet-Geräten und bietet gleichzeitig Gigabit-Glasfaser-Uplink-Optionen, die für ein Unternehmen-Netzwerk geeignet sind. Der Switch verfügt über eine umfangreiche Suite von Layer-2-Switching-Protokollen, einschließlich portspezifischer Betriebsmodi (Switching, Mirroring oder Aggregation), und ist mit einem 1.3 Zoll-LCM-Farb-Touchscreen ausgestattet, der wichtige System- und Verbindungsoptionen übersichtlich anzeigt. Mit der leistungsstarken, intuitiven UniFi-Netzwerk-Webanwendung und der mobilen App kann dieser Switch von überall aus überwacht und konfiguriert werden.
Vergleich mit ähnlichen Produkten
| Ethernet Ports | ||||||
| 48 x 1 Gbps | 16 x 1 Gbps | 24 x 1 Gbps | 24 x 1 Gbps | 48 x 1 Gbps | 8 x 1 Gbps | |
| PoE Standards | ||||||
| 16 x Passive PoE, 802.3af (PoE), 802.3at (PoE+) | 24 x Passive PoE, 802.3af (PoE), 802.3at (PoE+) | 48 x Passive PoE, 802.3af (PoE), 802.3at (PoE+) | 8 x Passive PoE, 802.3af (PoE), 802.3at (PoE+) | |||
| SFP Ports | ||||||
| 2 x 1G SFP, 2 x 10G SFP+ | 2 x 1G SFP | 2 x 1G SFP | 2 x 1G SFP | 2 x 1G SFP, 2 x 10G SFP+ | 2 x 1G SFP | |
| Management | ||||||
| Ethernet | Ethernet | Ethernet | Ethernet | Ethernet | Ethernet | |
| Maximale Leistungsaufnahme | ||||||
| 56 W | 150 W | 25 W | 250 W | 500 W | 150 W | |
| Betriebstemperatur | ||||||
| -5 °C to 40 °C | -5 °C to 40 °C | -5 °C to 40 °C | -5 °C to 40 °C | -5 °C to 40 °C | -5 °C to 45 °C | |
| Maße | ||||||
| 443 x 43 x 286 mm | 443 x 43 x 221 mm | 443 x 43 x 221 mm | 485 x 43.7 x 285.4 mm | 485 x 43.7 x 374.6 mm | 235 x 43 x 204 mm | |
| Gewicht | ||||||
| 3.65 kg | 2.89 kg | 2.6 kg | 4.7 kg | 6.1 kg | 1.65 kg | |
| Montagemethode | ||||||
| RackMount | RackMount, Wandhalterung | RackMount | RackMount | RackMount | Wandhalterung, Tisch | |
| Ethernet Ports | 48 x 1 Gbps | 16 x 1 Gbps | 24 x 1 Gbps | 24 x 1 Gbps | 48 x 1 Gbps | 8 x 1 Gbps |
| PoE Standards | 16 x Passive PoE, 802.3af (PoE), 802.3at (PoE+) | 24 x Passive PoE, 802.3af (PoE), 802.3at (PoE+) | 48 x Passive PoE, 802.3af (PoE), 802.3at (PoE+) | 8 x Passive PoE, 802.3af (PoE), 802.3at (PoE+) | ||
| SFP Ports | 2 x 1G SFP, 2 x 10G SFP+ | 2 x 1G SFP | 2 x 1G SFP | 2 x 1G SFP | 2 x 1G SFP, 2 x 10G SFP+ | 2 x 1G SFP |
| Management | Ethernet | Ethernet | Ethernet | Ethernet | Ethernet | Ethernet |
| Maximale Leistungsaufnahme | 56 W | 150 W | 25 W | 250 W | 500 W | 150 W |
| Betriebstemperatur | -5 °C to 40 °C | -5 °C to 40 °C | -5 °C to 40 °C | -5 °C to 40 °C | -5 °C to 40 °C | -5 °C to 45 °C |
| Maße | 443 x 43 x 286 mm | 443 x 43 x 221 mm | 443 x 43 x 221 mm | 485 x 43.7 x 285.4 mm | 485 x 43.7 x 374.6 mm | 235 x 43 x 204 mm |
| Gewicht | 3.65 kg | 2.89 kg | 2.6 kg | 4.7 kg | 6.1 kg | 1.65 kg |
| Montagemethode | RackMount | RackMount, Wandhalterung | RackMount | RackMount | RackMount | Wandhalterung, Tisch |
Spezifikationen
Interfaces
RJ45 Ports
(48) 1 Gbps
PoE Standards
ohne PoE
SFP Ports
(2) 1G SFP, (2) 10G SFP+
Kommunikationsschnittstellen
RJ45
Management
Ethernet
Power
Leistungsverfahren
AC/DC Adapter
Stromversorgung
Internes Netzteil, Externe AC/DC Netzteile
Unterstützte Eingangsspannung
100 - 240 V AC
Maximale Leistungsaufnahme
56 W
Stromanschlüsse
DC Stecker 2.1 x 5.5 mm
Physical Parameters
Farbe
Silber
Anzahl von Rack-Produkte
1U
Maße
443 x 43 x 286 mm
Gewicht
3.65 kg
Betriebstemperatur
-5 °C bis 40 °C
Umwelt
Innen
Montagemethode
RackMount
Formfaktor
Rack-mounted 19"
